RUGGEDCOM RX1501
Installation Guide
Chapter 2
Installing the Device
Connecting Low DC Power 19
2
1
Figure15:Chassis Ground Connection
1.#10-32 Screw 2.#10 Ring Lug
7. Install the safety cover over the terminal block. This is mandatory for 48 VDC or -48 VDC power supplies.
