Siemens RWF50.3 - 3 Installation; 3.1 Installation site and climatic conditions; 3.2 Dimensions

14/64
Building Technologies Division User Manual RWF50... CC1U7866en
Infrastructure & Cities Sector 3 Installation 25.07.2014
3 Installation
3.1 Installation site and climatic conditions
- The installation site should be free from vibrations, dust and corrosive media
- The controller should be installed away from sources of electromagnetic fields, such
as variable speed drives or high-voltage ignition transformers
Relative humidity: 95% (noncondensing)
Ambient temperature: -20...50 °C
Storage temperature: -40...70 °C
3.2 Dimensions
7866m01/0714
104
50
Figure 2: Dimensions of RWF50...
Key
(1) USB interface setup
(2) Panel cutout
