Siemens SCALANCE S602 - DIN Rail Mounting

Mounting
5.2 Types of installation
SCALANCE S
32 Commissioning and Hardware Installation Manual, 05/2016, C79000-G8976-C266-06
5.2.1
Installation on a DIN rail
Installation
Install the SCALANCE S on a 35 mm DIN rail complying with DIN EN 50022.
1. Place the upper catch of the device over the top of the DIN rail and then push in the lower
part of the device against the rail until it clips into place.
2. Install the electrical connecting cables and the terminal block for the signaling contact.
Image 5-1 SCALANCE S installation on a DIN rail (35 mm)
