Siemens SCALANCE S615 User Manual

Connecting up
5.6 Replacing the PLUG
SCALANCE S615
56 Operating Instructions, 10/2022, C79000-G8976-C389-07
5.6 Replacing the PLUG
NOTICE
Do not remove or insert a C-PLUG / KEY-PLUG during operation!
A PLUG may only be removed or inserted when the device is turned off.
The device checks whether or not a PLUG is present at one second intervals. The device
restarts if it is detected that the PLUG has been removed.
If a valid KEY-PLUG was inserted in the device, the device changes to a defined error state
following the restart.
Inserting the PLUG
1. Turn off the power to the device.
2. Insert the PLUG correctly oriented into the slot.
To ensure this, the housing of the PLUG has a protruding ridge on the long side. The slot
has a groove at this position.

Siemens SCALANCE S615 Specifications

General

Protocols	IPsec, OpenVPN
Power Supply	24 V DC
Mounting Type	DIN Rail
Product Name	SCALANCE S615
Ports	5
Firewall	Yes
Weight	0.6 kg
Certifications	CE
