SCALANCE S615
Operating Instructions, 10/2022, C79000-G8976-C389-07
63
Technical specifications
8
SCALANCE S615
Article number
6GK5 615-0AA00-2AA2
6GK5 615-0AA01-2AA2
Ethernet interface
Attachment to
Industrial Ethernet
Quantity
5
Design
RJ-45 jack
Characteristics:
10/100BASE-T
Ethernet IEEE 802
10/100 Mbps
Electrical data
Power supply
Input voltage
12 to 24 VDC
min. 10.8 VDC, max. 28.8 V
Maximum power
consumption
3 W
Digital input
Quantity
1
Design
Terminal block, 2 terminals
Characteristics:
Rated voltage 24 VDC Safe Extra Low Voltage
(SELV)
For state "1": 13 to 30 VDC
For state "0": -30 to 3 VDC
Maximum input current 8 mA
Cables should be routed in pairs
Maximum cable length < 30 m
Inputs isolated from electronics.
Digital output
Quantity
1
Design
Terminal block, 2 terminals
Properties
Rated voltage 24 VDC Safe Extra Low Voltage
(SELV)
internally not current limited
Maximum current carrying capacity 1 A
Cables should be routed in pairs
Maximum cable length < 30 m
Output isolated from electronics
Permitted ambient conditions
