Page #53 background image
SCALANCE W774-1 /W734-1
Operating Instructions, 01/2017, C79000-G8976-C325-08
53
Technical data
7
7.1
Technical specifications W774/W734 RJ-45
The following technical specifications apply to the following devices:
SCALANCE W774-1 RJ-45
SCALANCE W734-1 RJ-45
Note
You will find detailed
information on the transmit power and receiver sensitivity in the
document "Performance data 802.11 abgn SCALANCE W770/W730" on the supplied data
medium (REF_W770
-RadioInterface.pdf).
Technical specifications
Data transfer
Ethernet transfer rate
10 / 100 Mbps
Wireless transmission rate
1 ... 300 Mbps
Wireless standards supported IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Power supply standards supported Standards IEEE 802.3at type 1 (802.3af)
802.3at type 2 (Power over Ethernet)
Class
Class 2 *
)
Mode
Mode A (phantom power)
Attachment to Industrial Ethernet
Quantity
2
Design
RJ-45 jack
Properties
Half duplex/full duplex, autocrossover, autonegotiation, autosensing, PoE, floating
Permitted cable lengths (Ethernet)
(Alternative combinations per length range)
IE TP torsion cable 0 ... 55 m
0 ... 45 m + 10 m TP cord
IE FC TP marine cable
IE FC TP trailing cable
IE FC TP flexible cable
IE FC TP FRNC cable
IE FC TP festoon cable
IE FC TP food cable
0 ... 85 m
0 ... 75 m + 10 m TP cord
