Device variant Power loss at
24 VDC
Current consumption at
rated voltage 24 VDC
Overcurrent protection
at input (non-replacea‐
ble fuse)
X307-3,
X307-3LD,
X308-2,
X308-2LD,
X308-2LH,
X308-2LH+,
X310,
X310FE,
X320-1 FE
9.6 W 400 mA 3 A / 32 V
X320-3LD FE 12 W 500 mA 3 A / 32 V
Table 8-7 Electrical data: Signaling contact
Voltage via signaling contact 24 VDC
Switching capacity (resistive load) max. 100 mA
Resistor between F1-F2 < 8 Ω
Table 8-8 Plug-in terminal block for connectors of the power supply and signaling contact
Power supply 1 x 4-pin
Signaling contact 1 x 2-pin
Table 8-9 Electrical data: Transmitter output (optical) and receiver input
Device variant Transmitter output (optical) Receiver input
min. [dBm] max. [dBm] Sensitivity min. [dBm] Input power max.
[dBm]
X304-2FE -19 -14 -32 -3
X306-1LD FE -15 -8 -34 -3
X307-3 -9.5 -4 -17 -3
X307-3LD -9.5 -3 -21 -3
X308-2 -9.5 -4 -17 -3
X308-2LD -9.5 -3 -21 -3
X308-2LH -6 0 -23 -3
X308-2LH+ 0 5 -23 -3
X310 - - - -
X310FE - - - -
X320-1 FE -19 -14 -32 -3
Technical specifications
8.2 X-300 technical specifications
SCALANCE X-300
156 Operating Instructions, 11/2019, A5E01113043-24
