Recommendation for the attenuation of the attenuator on a connection with the same
transceivers:
Transceiver type Attenuator
LH 6 dB ... 12 dB
LH+ 12 dB ... 20 dB
ELH, ELH200 16 dB ... 24 dB
If you have established a connection on a pluggable transceiver with a short cable length, it is
possible that the transmitter will be turned off. In this case, pull the transceiver and plug it in
again.
GI-PCF
For segment lengths longer than 100 m, you can use GI-PCF cables. Note the information of
the manufacturer.
8.9.4 Other properties
Table 8-109 Mean time between failure (MTBF)
Device version (power supply) MTBF
1)
MM992-2CUC,
MM992-2CUC (C),
MM992-2CU,
MM992-2M12 (C)
> 250 years
MM991-2P (SC RJ) > 230 years
MM992-2VD > 200 years
MM991-2 (BFOC)
MM991-2 (SC)
> 140 years
MM991-2FM (BFOC)
MM992-2 (C) (SC)
> 135 years
MM991-2LD (BFOC)
MM991-2LD (SC)
MM992-2LD (LD)
> 115 years
MM991-2LH+ (SC)
MM992-2LH (SC)
MM992-2LH+ (SC)
> 105 years
MM992-2ELH (SC) > 95 years
MM992-2SFP
2)
> 250 years
3)
1)
These values apply at 40 °C
2)
You will find further information in the compact operating instructions "Transceiver SFP/SFP+".
3)
empty
Technical specifications
8.9 MM900 technical specifications
SCALANCE X-300
210 Operating Instructions, 11/2019, A5E01113043-24
