Table 8-41 Mechanical stability
Strain withstood / category (standard) Test conditions
Vibration
(IEC 60068-2-6)
Frequency range 10 Hz to 150 Hz:
● Transit frequency: 58 Hz to 60 Hz
● Peak value of the displacement [mm] below the transit
frequency: 0.075
● Peak value of the acceleration [g] above the transit
frequency: 1
● Number of cycles per axis: 20
Frequency range 5 Hz to 150 Hz:
● Transit frequency: 8.4 Hz
● Peak value of the displacement [mm] below the transit
frequency: 3.5
● Peak value of the acceleration [g] above the transit
frequency: 1
● Number of cycles per axis: 10
● Octaves / min: 1
Frequency range 2 Hz to 100 Hz:
● Frequency range: 2 Hz to 100 Hz
● Transit frequency: 13.2 Hz
● Peak value of the displacement [mm] below the transit
frequency:1
● Peak value of the acceleration [g] above the transit
frequency: 0.7
● Number of cycles per
Vibration
(IEEE1613 Class V.S.2)
● Velocity: <10 mm/s
● Frequency: 1 to 150 Hz
Shock
(IEC 60068-2-27)
● Acceleration: 15 g
● Duration of the pulse: 11 ms
● Number of shocks per direction: 3
