Assembly
4.2 Installing/uninstalling the EM495-8 twisted pair extender for SCALANCE X414-3E
SCALANCE X-400 extender modules
22 Compact Operating Instructions, 04/2013, A5E00367421-10
Installing the twisted pair extender on the 35 mm DIN rail
CAUTION
If the IE Switch X-400 with extender is liable to severe vibration (> 10 g), use the S7-300
standard rail for installation. The DIN rail does not provide adequate support for the twisted
pair extender with vibration greater than 10 g.
For installation, you require a slotted screwdriver with a 2.8 mm wide blade.
Although the captive screw in the lower part between slots 12 and 13 of the extender module
is not used when installing on a 35 mm DIN rail, it is nevertheless advisable to remove the
media modules.
Note
Make sure that in addition to the extender width of 87 mm, there is a clearance of 20 mm to
the right of the basic device on the DIN rail to be able to align the guide bolts of the extender
with the holes in the basic device during installation.
When installing a twisted pair extender on a 35 mm DIN rail, the basic device remains in
position. Follow the steps below:
1. Remove the cover from slot 11 of the basic device.
2. Remove the right-hand side panel of the basic device. To do this, use a slotted
screwdriver with a 2.8 mm wide blade to loosen the two captive slug screws on slot 11 in
the upper and lower recesses as far as they will go.
3. Remove the side panel of the basic device from the basic device to the right.
Note
Keep the panel in a safe place in case the extender needs to be removed again later.
4. Place the central groove containing a spring clip on the back of the extender module on
the upper edge of the DIN rail with the module tilted slightly towards the back. Make sure
that there is adequate clearance between the guide bolts of the extender module and the
basic device.
5. The spring clip must be located behind the edge of the DIN rail so that it is visible from
the rear of the frame.
6. Press the extender module down and push in the lower part until you hear it click into
place in the DIN rail.
7. Push the extender module slowly to the left while keeping it straight and without skewing
and check that the two guide bolts on the extender fit into the holes in the basic device.
Then push the extender module to the left as far as it will go so that it is flush with the
right side of the basic device.
