Network topologies
3.3 Ring with redundancy manager
SCALANCE X-300
42 Operating Instructions, 05/2016, A5E01113043-20
Device
Factory setting for the ring ports
Electrical
Optical
XR324-12M TS
Port 1.1 and port 1.2
XR324-4M EEC
Port 1 and port 2
XR324-4M PoE Port 1 and port 2
XR324-4M PoE TS
Port 1 and port 2
Configuration example
Sample configurations with IE Switch X-300, SIMATIC S7-200/300/400, operator control and
monitoring system, H system, and PC as end devices.
Image 3-3 Gigabit ring with redundancy manager (RM)
