Description of the device
4.2 Product groups
SCALANCE X-300
62 Operating Instructions, 05/2016, A5E01113043-20
Possible attachments (example)
Use only approved media modules in the module slots
The connection of end devices or other network segments does not depend on the module
slot, but rather on the selected media module.
Refer to the section Media module installation in slot.
Image 4-14 SCALANCE X308-2M with MM992-2 and MM991-2
MM992-2 MM991-2
P5 P7
P6 P8
- Optical:
Connection type depending on module
used
