Description of the device
4.2 Product groups
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
81
Note
Installation of the XR-300M, XR-300M PoE and XR-300M EEC
Only the lower slots may be equipped with the MM991
-2P.
XR-300M: Maximum 6 modules in slots 7 to 12
XR-300M PoE, XR-300M EEC: Maximum 2 modules in slots 3 and 4
-2P may only be used as follows:
Without media module
With media module MM992-2CUC or MM992-2CU
-300M: If the MM991-2P is plugged into slot 8, an MM992-2CUC may be used
See also table: "Operating temperature with media module MM991
-2P"
MM992-2 product characteristics
Possible attachments
The MM992-2 media module has the following:
● 2 x 1000 Mbps, SC port optical, (multimode glass), up to max. 750 m
Image 4-37 MM992-2 [9922AL]
[Device labeling in square brackets]
