4.2.10 SCALANCE X310FE
Possible attachments
The SCALANCE X310FE provides the following options for the connection of end devices or
other network segments:
ā— 10 RJ-45 jacks
Figure 4-10 SCALANCE X310FE
Column 1 2 3 4
Port number P1 P5 P8 P9
P2 P6 - P10
P3 P7 - -
P4 - - -
Connection
type
Electrical: Fast Ethernet
Device description
4.2 Product properties and device views
SCALANCE X-300
30 Compact Operating Instructions, 11/2019, A5E00982643-18
