3.3.2 Device view of a SCALANCE XB112
The following figure shows an overview of the components of the SCALANCE XB112.




① Electrical ports with port LEDs
② Power LEDs
③ Redundant power supply with connector for grounding
3.3.3 Device view of a SCALANCE XB116
The following figure shows an overview of the components of the SCALANCE XB116.




① Electrical ports with port LEDs
② Power LEDs
③ Redundant power supply with connector for grounding
Description of the device
3.3 Device views
SCALANCE XB-100
14 Operating Instructions, 02/2019, C79000-G8976-C473-03
