Siemens SCALANCE XR328-4C WG User Manual

Description of the device
3.4 RESET button
SCALANCE XR-300WG
Operating Instructions, 05/2017, C79000-G8976-C454-01
23
Pluggable transceiver slots
There is an LED for each plug-in transceiver slot.
LED color
LED status
Meaning
Green
Lit
Link exists
Yellow Flashing Data transfer at the port
-
Off
No link exists
3.4
RESET button
WARNING
EXPLOSION HAZARD
Do not press the RESET button if there is a potentially explosive atmosphere.
Position
The "RESET" button is located on the front of the SCALANCE XR-300WG.
Figure 3-1 Position of the "RESET" button on the SCALANCE XR-300WG
Resetting the device to factory defaults
NOTICE
Previous settings
If you reset, all the settings you have made will be overwritten by factory defaults.
NOTICE
Inadvertent reset
An inadvertent reset can cause disturbances and failures in the configured network.
