Siemens SCALANCE XR328-4C WG User Manual

Technical specifications
7.2 Technical specifications of the SCALANCE XR328-4C WG
SCALANCE XR-300WG
Operating Instructions, 05/2017, C79000-G8976-C454-01
51
Technical specifications
Dimensions (W x H x D)
482.6 x 43.6 x 177 mm
Weight
3300 g
Installation options
19" rack mounting
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40
°C)
> 50 years
7.2
Technical specifications of the SCALANCE XR328-4C WG
7.2.1
24 VDC variant
The following technical specifications apply to the 24 VDC variant of the SCALANCE XR328-
4C WG.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors
Quantity
24
Connector
RJ-45 jack
Properties
Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Combo ports
Quantity
4
Electrical connect-
ors
Quantity
4
Connector
RJ-45 jack
Properties
Half/full duplex, MDI-X pinning
Transmission speed
10 / 100/ 1000 Mbps
Slots for pluggable
transceivers
Quantity
4
Connector
SFP transceiver
Transmission speed
1000 Mbps
Diagnostics interface
Serial interface Quantity 1
Connector RJ-11 jack
Electrical data
Power supply
Design
Terminal block, 2 terminals
Rated voltage 24 VDC
Voltage range
19.2 to 28.8 VDC Safe Extra Low Voltage (SELV)
Cable cross section
≥ 0.75 mm
2
(20 AWG)
Property Implemented redundantly
