28/80
Siemens Building Technologies Commissioning Guide CM1G5192en
HVAC Products 6 Commissioning 26.02.2003
6.5 Quick commissioning
Quick commissioning allows the user to get started in the shortest possible time.
The grayed out parameters can be left as the VSD will calculate a value or use the factory default values. We sug-
gest to check these values before the VSD is put into service.
Parameter Default Set to Function
P0010
1 = Quick
commissioning
01
Start quick commissioning
P0010 must always be set back to “0” before operating the motor.
However if P3900 is set = 1 after commissioning, this is carried out
automatically
P0100
0 = kW / 50 Hz
1 = hp / 60 Hz
2 = kW / 60 Hz
0 0
For use in Europe / N. America
For setting 0 and 1 use DIP switch 2
For setting 2 use P0100
P0304
10 – 2000 V
230
Motor
plate
Rated motor voltage
Nominal motor voltage (V) from rating plate
P0305
0 ... 10,000 I/nom
3.25
Motor
plate
Rated motor current
Nominal motor current (A) from rating plate
P0307
0 – 2000 kW
0.75 Motor
plate
Rated motor power
Nominal motor power (kW) from rating plate. If P0100 = 1, values will
be in hp
P0308
0 -1.000
0
Motor
plate
Rated motor power factor
Nominal cosPhi from rating plate
P0309
0
Motor
plate
Rated motor efficiency
Nominal motor efficiency from rating plate
P0310
12 - 650 Hz
50.00
Motor
plate
Rated motor frequency
Nominal motor frequency (Hz) from rating plate
P0311
0 - 40000 1/min
0
Motor
plate
Rated motor speed
Nominal motor speed (rpm) from rating plate
P0700[2]
Index 0: Auto
Index I : Hand
2
1
2
1
Selection of command source (on / off )
1 = BOP
2 = Terminal / digital inputs
P1000[2]
Index 0: Auto
Index I : Hand
2
1
2
1
Selection of frequency setpoint
1 = BOP Basic Operator Panel
2 = Analog setpoint
P1080
10.00 Site
setting
Min. motor frequency (0 - 650 Hz): Sets the minimum motor fre-
quency at which the motor will run, irrespective of the frequency set-
point. The value set here is valid for both clockwise and counterclock-
wise rotation
P1082
50.00 Site
setting
Max. motor frequency (0 – 650 Hz): Sets the maximum motor fre-
quency at which the motor will run, irrespective of the frequency set-
point. The value set here is valid for both clockwise and counterclock-
wise rotation (do not normally set this higher than 50 Hz unless the
motor can be used at higher frequencies)
P1120
10 Site
setting
Ramp-up time (0 - 650 s): Time taken for the motor to accelerate from
standstill up to maximum motor frequency
P1121
30 Site
setting
Ramp-down time (0 - 650 s): Time taken for the motor to decelerate
from maximum motor frequency down to standstill
P3900
01
P3900 end quick commissioning
0 = End without motor calculation or
factory reset
1 = End with motor calculation and
factory reset (recommended)
2 = End with motor calculation and
with I/O reset
3= End with motor calculation but
without I/O reset
