Technical data
12
12.1
DC geared motor
Supply voltage
24 VDC
Maximum speed
0.5 m/s
Degree of protection
IP 21
Gear ratio 15:1
Pulse generator
100 pulses/revolution
Rated current 1.8 A
12.2
Control unit
Supply voltag
230 V, 50 to 60 Hz
Tolerance
± 15 %
On-site protection
6 A to 10 A (I²t > 30 A²s)
Maximum power consumption
1.6 A
Degree of protection
IP 20
Control inputs +10 VDC to +28 VDC, 6 mA to 18 mA per input (potential-
free, switching to P potential)
Door width
0.3 m to 2.40 m
Maximum counterweight
4 kg
Output relay switching capacity
30 VDC, 0.5 A (10 mA min.)
Max. perm. storage temperature
- 20 to + 85°C
Max. perm. operating temperature
- 0 to + 50°C
Moisture requirement
No condensation
24 V output Max. output current 120 mA, short-circuit and overload-proof
CAUTION: Do not supply with external voltage!
12.3
Regulations and standards
EMC tests
EN 12015 and EN 12016
TÜV (German Technical Inspectorate) Type-tested
CE
Certified
Electrical safety according to EN 60950 Conforming
Elevator standard EN 81
Conforming
Recycling and disposal
For ecologically sustainable recycling and disposal of your old device, contact a certificated
disposal service for electronic scrap or dispose of the device in accordance with the
regulations in your country.
