Siemens SIDOOR AT12 - Diagnostics and Parameterization

Appendix
A.8 Diagnostics and parameterization
Elevator door drive AT12
44 Manual, 02/2012, A2B00086683A-04
A.8 Diagnostics and parameterization
The Service Tool and the Sidoor User Software can be used equally well for diagnostics and
setting the parameters
These tools are optionally available (see Appendix Order nos. of the individual parts
(Page 37)).
The Service Tool and the USB adapter
for the Software Kit (Sidoor User Software) can be
connected to X102 on the controller with the associated cable.
The tool keys and buttons have identical inscriptions and functions.
Enter key, jumps to the next menu below
Escape key, jumps back to the menu above
Menu selection key, increases a parameter value
Menu selection key, decreases a parameter value
Parameters can be changed in the
"MAIN MENU QUICK ADJUSTMENT → Parameter
Setting"
and in the "MAIN MENU TOTAL ADJUSTMENT → Profile Parameter" menus.
The desired parameter is selected with the
or the key, and activated for the setting
with the Return key
(parameter value flashes).
The parameter value can then be increased or decreased by pressing the corresponding key
(see above).
The value is accepted by pressing the Return key again.
