2AI U ST analog electronic module (6ES7134-4FB01-0AB0)

Manual, 04/2007, A5E01076000-01

Parameters

2.1 Parameters

Table 2-1 Parameters for analog input module

2 AI U ST Range of values Default setting Applicability

Group diagnostics (parameter

assignment error, internal error)

• Disable

• Enable

Disable Module

Diagnostics: Overflow/underflow

• Disable

• Enable

Disable Module

Diagnostics: Wire break*

• Disable

• Enable

Disable Channel

Smoothing

• None

• Weak

• Medium

• Strong

None Channel

Type/range of measurement

• Deactivated

• ±5 V

• ±10 V

• 1 to 5 V

±10 V Channel

* Only in the measuring range of 1 to 5 V
