Diagnostics
3.2 Error types
2AI U ST analog electronic module (6ES7134-4FB01-0AB0)
14 Manual, 04/2007, A5E01076000-01
3.2 Error types
Analog input module error types
Table 3-1 Error types
Error type Meaning Remedy
16
D
10000: Parameter
assignment error
Module cannot use the
parameter for the channel:
Inserted module does not
match the one configured.
Incorrect parameter
assignment.
Correct the configuration (align
actual and set configuration).
Correct the parameter
assignment (wire break
diagnostics only parameterized
for the permitted measuring
ranges).
9
D
01001: Error Internal module error
(diagnostic message at channel
0 applies to the entire module)
Replace the module.
7
D
00111: Upper limit
exceeded
Value is above the overshoot
range.
Correct the module/final
controlling element tuning.
8
D
01000: Lower limit
value undershot
Value is below the underrange. Correct the module/final
controlling element tuning.
6
D
00110:
Open circuit
Line to the encoder interrupted. Correct the process wiring.
