Siemens SIMATIC 6ES7134-4FB01-0AB0 User Manual

Properties
1.1 2AI U ST analog electronic module (6ES7134-4FB01-0AB0)
2AI U ST analog electronic module (6ES7134-4FB01-0AB0)
Manual, 04/2007, A5E01076000-01
9
2AI U ST technical specifications (6ES7134-4FB01-0AB0)
Dimensions and weight
Width (mm) 15
Weight Approx. 40 g
Module-specific data
Supports isochronous operation No
Number of inputs 2
Cable length
• Shielded
Max. 200 m
Parameter length 4 bytes
Address space 4 bytes
Voltages, currents, potentials
Rated load voltage L+ (from the power module) 24 VDC
• Reverse polarity protection
Yes
Electrical isolation
• Between the channels and backplane bus
Yes
• Between the channels and load voltage L+
Yes
• Between the channels
No
Permissible potential difference
• Between the inputs and M
ANA
(U
CM
)
2 VAC
SS
• Between M
ANA
and the central grounding point
(U
ISO
)
75 VDC / 60 VAC
Insulation tested 500 VDC
Current consumption
• From load voltage L+
Max. 30 mA
Power dissipation of the module Typically 0.6 W
Status, interrupts, diagnostics
Diagnostics function
• Group error
Red "SF" LED
• Diagnostic functions readable
Yes
Analog value generation
Measuring principle Integrative
Integration and cycle time/resolution per channel:
• Integration time can be assigned parameters
Yes
• Interference frequency suppression in Hz
60 50
• Integration time in ms
16,7 20
• Conversion time in ms
55 65
• Cycle time in ms
Number of active channels per module x
conversion time
• Resolution (including overshoot range)
± 10 V/13 bits + sign
± 5 V/13 bits + sign
1 V to 5 V/13 bits

Siemens SIMATIC 6ES7134-4FB01-0AB0 Specifications

General

Brand	Siemens
Model	SIMATIC 6ES7134-4FB01-0AB0
Category	I/O Systems
Language	English
