BusAdapter BA 2xFC
5.2 Connecting
BusAdapter
Equipment Manual, 08/2020, A5E41449003-AB
21
5.2 Connecting
Installing the bus connector
Install the PROFINET connector according to the instructions in the PROFINET Installation
Guide (https://www.profibus.com/).
Tools required
3 to 3.5 mm screwdriver, alternatively TX10 (torx).
Accessories required
• If you use Fast Connect Cable, we recommend the Industrial Ethernet Fast Connect
Stripping Tool (6GK1901-1GA00) with green knife cassette (6GK1901-1B). This
guarantees fast and safe stripping.
• Fast Connect Cable (recommended types):
– IE FC TP Standard Cable GP 2x2 (6XV1840-2AH10)
– IE FC TP Trailing Cable 2x2 (6XV1840-3AH10)
– IE FC TP Marine Cable (6XV1840-4AH10)
– IE FC TP Flexible Cable GP 2x2 (6XV1870-2B)
– IE FC TP Trailing Cable 2x2 (6XV1870-2D)
– IE TP Torsion Cable 2x2 (6XV1870-2F)
– FC TP FRNC Cable GP (6XV1871-2F)
– IE FC TP Food Cable GP 2x2 (6XV1871-2L)
– IE FC TP Festoon Cable 2x2 (6XV1871-2S)
• Please observe the specifications in the PROFINET Installation Guide
(https://www.profibus.com/).
