Siemens SIMATIC BusAdapter User Manual

BusAdapter BA 2xFC
5.2 Connecting
BusAdapter
24 Equipment Manual, 08/2020, A5E41449003-AB
BusAdapter BA 2xFC installed
①
CPU
②
BusAdapter BA 2xFC
③
PROFINET connecting cable
④
Connection element
Figure 5-4 BusAdapter BA 2xFC installed (using an ET 200SP CPU/interface module as an example)
Note
Installation guidelines for modules with PROFINET
IO interfaces
Ensure that all devices are connected to the SELV/PELV power supply (or equivalent). Only
then are you permitted to operate the modules with PROFINET
IO interfaces in LAN networks
(Local Area Networks).
A data transfer point that guarantees this degree of
safety is prescribed for connection to the
WAN (Wide Area Network).
