BusAdapter BA 2xLC
7.2 Connecting
BusAdapter
Equipment Manual, 08/2020, A5E41449003-AB
37
Procedure
To connect PROFINET IO to the PROFINET device via the BusAdapter BA 2xLC, follow these
steps:
1. Plug the BusAdapter BA 2xLC into the PROFINET device.
2. Screw the BusAdapter BA 2xLC to the PROFINET device (1 screw with 0.25 Nm tightening
torque). To do this, use a screwdriver with a 3 to 3.5 mm blade, alternatively TX10.
3. Remove the blanking plugs from the PROFINET sockets.
4. Hold the prepared connector by the housing. Insert it into the PROFINET socket on the
BusAdapter BA 2xLC until you hear it click into place. The coding of the connectors ensures a
safe connection.
Risk of damage to eyes
Do not look directly into the opening of the optical transmitter diodes. The emitted light
