Mechanical ambient conditions
The mechanical ambient conditions for the described components are specified in the table
below for sinusoidal vibrations.
Frequency range in Hz Continuous Infrequently
10 ≤ f ≤ 58 0.0375 mm amplitude 0.075 mm amplitude
58 ≤ f ≤ 150 0.5
g
constant acceleration 1
g
constant acceleration
Reduction of vibrations
If the described components are subject to big shocks or vibrations appropriate measures must
be taken to reduce the acceleration or the amplitude.
We recommend fixing the described components on damping materials (rubber-metal anti-
vibration mountings, for example).
Checking mechanical ambient conditions
The following table provides information on the type and scope of checks regarding mechanical
ambient conditions.
Checking for Test standard Remarks
Vibrations Vibration test according to
IEC 60068 Part 2-6 (sinusoi‐
dal)
Type of vibration:
Frequency sweeps with a sweep rate of 1 octave/mi‐
nute.
5 Hz ≤ f ≤ 8.4 Hz, constant amplitude 3.5 mm
8.4 Hz ≤ f ≤ 150 Hz, constant acceleration 1 g
Period of oscillation: 10 frequency sweeps per axis in
each of the 3 axis which are vertical to each other.
Shock Shock test in accordance
with IEC 60068 Part 2-29
Type of shock: half-sine
Strength of shock:
15 g peak value, 11 ms duration
Shock direction:
3 shocks each in +/- direction in each of the 3 axes
that are vertical to each other
Climatic ambient conditions
The described components can be used in the following climatic ambient conditions:
Ambient conditions Permitted range Remarks
Temperature:
Horizontal installation
Vertical installation
from -40 to 70 °C
from -40 to 50 °C
● Compact FF Link
6ES7655-5BA00-0AB0
● BM Compact FF Link
6ES7655-5EF00-0AA0
Temperature:
any type of installation from -40 to 70 °C
Active field distributors
See Operating Instructions
DP/PA coupler, Ac‐
tive Field Distributor, DP/PA Link and Y Link
Technical data
12.1 General technical data
Compact FF Link
