Configuring and Parameterizing the CP 340
5.5 Identification data
PtP coupling and configuration of CP 340
Manual, 04/2011, A5E00369892-03
99
Identification data of the CP 340 module
Table 5- 4 Identification data of the CP 340 module
Identification data Access Default setting Description
Index 1 (data record 231/read only)
Manufacturer Read
(2 bytes)
00 2A hex (= 42 dec) The name of the manufacturer is saved to this
parameter (42 dec = Siemens AG).
Device name Read
(20 bytes)
6ES7 340–1xH02–0AE0 Order number of the module
x = A(RS232), B(TTY), C(RS422/485)
Device serial number Read
(16 bytes)
The serial number of the module is saved to this parameter. This structure
allows the unique identification of the module.
Hardware revision Read
(2 bytes)
Provides information about the product version of the module.
Software revision Read
(4 bytes)
Provides information about the firmware version of the module.
Statistical
revision no.
Read
(2 bytes)
- Not supported
Profile_ID Read
(2 bytes)
F6 00 hex Internal parameter
(to PROFIBUS DP)
Profile–specific type Read
(2 bytes)
00 04 hex (= 4 dec) Internal parameter (communication module, to
PROFIBUS DP)
I&M version Read
(2 bytes)
00 00 hex (= 0 dec) Internal parameter
(to PROFIBUS DP)
I&M supported Read
(2 bytes)
00 01 hex (= 1 dec) Internal parameter (I&M0 and I&M1, to
PROFIBUS DP)
Index 2 (data record 232/read and write)
HID Read/
write
(max.
32 characters)
- Plant designation of the module.
LD Read/
write
(max.
22 characters)
- Location designation of the module.
