Siemens SIMATIC ET 200SP Original Instructions

Ex-DI 4xNAMUR
Ex-DI 4xNAMUR
14 A5E50377423-AB, 03/2023
For use in the USA and Canada
The control drawing for the ET 200SP HA and the ET 200SP is supplied with the
respective power supply module.
The latest edition can also be found at
URL: (https://support.industry.siemens.com/cs/ww/en/)
(https://support.industry.siemens.com/cs/ww/en/
)
Technical specifications
Ex-DI 4xNAMUR
Supply voltage
Type of supply voltage
DC supply via Ex-PM-E
Input current
Current consumption (rated value)
50
mA
Current consumption, max.
55
mA
Encoder supply
Number of outputs
4
Output voltage (DC)
8.2
V
Short-circuit protection
Yes
Power loss
Power loss, typ.
1.2
W
Ex(i) characteristic values
Maximum values for terminals for gas
group IIC
Uo (output no-load voltage), max.
9.6
V
I
o
(short-circuit current), max.
61
mA
Valid for up to 4 electric
circuits connected in
parallel
Po (output power), max. 145 mW Valid for up to 4 electric
circuits connected in
parallel
C
o
(permissible external capacity), max.
3.6
µF
Valid for up to 4 electric
circuits connected in
parallel
Lo (permissible external inductance),
max.
13 mH Valid for up to 4 electric
circuits connected in
parallel

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
