Overview
1.2 Design of the OP 73micro HMI device
OP 73micro, TP 177micro (WinCC flexible)
12 Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
1.2 Design of the OP 73micro HMI device
Views of the HMI device
1
2
3
4
Figure 1-1 Front and side view
① Display
② Membrane keyboard
③ Clamping recess
④ Mounting seal
Figure 1-2 Bottom view
