Operating alarms
9.3 Operating alarms on the TP 177micro
OP 73micro, TP 177micro (WinCC flexible)
Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
135
9.3.3 Editing an Alarm
Introduction
The configuration engineer can assign additional functions to each alarm. These functions
are executed when the alarm is processed.
Requirements
● The alarm to be edited is indicated in the alarm window or in the alarm view.
● Either the alarm window or the alarm view is enabled.
Procedure
Proceed as follows to edit an alarm:
1. Select the alarm by touching it in the alarm view or alarm window.
2. Touch
.
Result
The system executes the additional functions of the alarm. Further information on this may
be available in your plant documentation.
Note
When you edit an unacknowledged alarm, it is acknowledged automatically.
See also
Displaying alarms (Page 132)
