Appendix
A.2 System alarms
OP 73micro, TP 177micro (WinCC flexible)
170 Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
Number Effect/cause Remedy
290007 There is a difference between the source and target
structure of the recipe currently being processed.
The target structure contains an additional data
recipe tag which is not available in the source
structure.
The data recipe tag specified is assigned its start
value.
Insert the specified data recipe tag in the source
structure.
290008 There is a difference between the source and target
structure of the recipe currently being processed.
The source structure contains an additional data
recipe tag which is not available in the target
structure and therefore cannot be assigned.
The value is rejected.
Remove the specified data recipe tag in the specified
recipe from the project.
290010 The storage location configured for the recipe is not
permitted.
Possible causes:
Illegal characters, write protection, data carrier out
of space or does not exist.
Check the configured storage location.
290011 The data record with the specified number does not
exist.
Check the source for the number (constant or tag value).
290012 The recipe with the specified number does not
exist.
Check the source for the number (constant or tag value).
290013 An attempt was made to save a data record under
a data record number which already exists.
The action is not executed.
The following remedies are available:
• Check the source for the number (constant or tag
value).
• First, delete the data record.
• Change the "Overwrite" function parameter.
290014 The file specified to be imported could not be
found.
Check:
• The file name
• Ensure that the file is in the specified directory.
290020 Message reporting that the download of data
records from the HMI device to the PLC has
started.
-
290021 Message reporting that the download of data
records from the HMI device to the PLC was
completed.
-
290022 Message reporting that the download of data
records from the HMI device to the PLC was
canceled due to an error.
Check in the configuration whether:
• The tag addresses are configured in the controller
• The recipe number exists
• The data record number exist
• The "Overwrite" function parameter is set
290023 Message reporting that the download of data
records from the PLC to the HMI device has
started.
-
290024 Message reporting that the download of data
records from the PLC to the HMI device was
completed.
-
