Appendix
A.2 System alarms
OP 73micro, TP 177micro (WinCC flexible)
174 Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
Number Effect/cause Remedy
320009 The diagnostic data stored in the configuration are
not synchronized with those in the PLC. The
diagnostic screens can be operated as usual.
ProAgent may be unable to show all diagnostic
texts.
Download the project to the HMI device again.
320010 The diagnostic data stored in the configuration are
not synchronized with those in STEP7.
The ProAgent diagnostics data is not up-to-date.
Download the project to the HMI device again.
320011 A unit with the corresponding DB number and FB
number does not exist.
The function cannot be executed.
Check the parameters of the "SelectUnit" function and the
units selected in the project.
320012 The "Step sequence mode" dialog is no longer
supported.
Use the ZP_STEP step sequence screen from the
corresponding standard project for your project. Instead
of calling the Overview_Step_Sequence_Mode function,
call the "FixedScreenSelection" function using ZP_STEP
as the screen name.
320014 The selected controller cannot be evaluated for
ProAgent.
The alarm view assigned to the
"EvaluateAlarmDisplayFault" system function could
not be found.
Check the parameters of the "EvaluateAlarmDisplayFault"
system function.
330022 Too many dialogs open on the HMI device. Close all dialogs you do not require on the HMI device.
