7-9
Equipment
Manual OP7, OP17
Release 04/99
The
event messages (EM) and alarm messages (AM) illustrated below are
queued on the OP
.
Message level
11:50 EM 02
12:08 EM 07
11:54 AM 01
12:01 AM 08
12:00 EM 04
11:55 AM 05
7.2.3 Viewing Event and Alarm Message Text
Irrespective
of the current contents of the event or alarm buf
fer
, all config
-
ured event and alarm message text can be shown on the OP
. T
o do so, pro
-
ceed as follows:
Step Procedure
1
Choose the standard screen
Alarms
T
ext
to display alarm messages or
Events
T
ext
to display event messages.
2
By using the arrow keys, you can now scroll
through the list of configured message text.
Example
Viewing
Messages
