Migrating a project
3.3 Switching screen from 4:3 to Widescreen
Migration Guide Comfort Panels
Getting Started, 03/2011, A5E03478626-01
29
3.3.3 Switchover with adaptation to screen
TP 177B 6" Setting TP700 Comfort
Adaptations for screens and
screen objects:
"Adapt width and height to new
screen"
Position:
"None"
[
The "Circle" object is only
increased, not distorted. A
"circle" always remains a
"circle".
Result
The screen size is stretched to the height and width of the target device.
Yes No
Distorted screen elements possible X
Truncated screen elements possible X
Greatly reduced screen elements possible X
