Migrating a project
3.4 Switching over the HMI device
Migration Guide Comfort Panels
36 Getting Started, 03/2011, A5E03478626-01
3.4 Switching over the HMI device
Requirements
● Adaptations for screens and screen objects are set for changing the display format (see
Switching screen from 4:3 to Widescreen (Page 27)).
● The projec
t tree is open in WinCC.
Procedure
Proceed as follows:
Result
The HMI device is changed over:
● The format of the screens is changed from 4:3 to Widescreen.
● The screen objects are placed according to the settings in the screens.
● The assignment of the function keys is migrated according to the function key
assignment.
