Technical information
8.8 Technical specifications
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
217
Power supply
Comfort V1 devices
KP1500 Comfort V1
TP1500 Comfort V1
TP1900 Comfort V1
TP2200 Comfort V1
Rated voltage
Permitted voltage range
24 V DC
+19.2 V to +28.8 V
Rated current 1.5 A 1.3 A 2.2 A
Rated current,
load-dependent
1.5 ... 3.5 A 1.3 ... 3.7 A 2.2 ... 4 A
Inrush current I
2
t 0.5 A
2
s
Power consumption
1
36 W
32 W
53 W
Maximum permitted transient
35 V (500 ms)
Minimum time between two
transients
50 s
Internal protection
Yes
1
The power loss generally corresponds to the specified value for power consumption.
Comfort V2 devices
KP1500 Comfort V2
TP1500 Comfort V2
TP1900 Comfort V2
TP2200 Comfort V2
Rated voltage
Permissible voltage range
24 V DC
+19.2 V to +28.8 V
Rated current
1.7 A
1.7 A
1.7 A
Rated current,
load-dependent
1.45 ... 2.1 A 1.4 ... 2.1 A 1.5 ... 2.1 A
Inrush current I
2
t
0.5 A
2
s
Power consumption
1
41 W
41 W
41 W
Maximum permitted transients
35 V (500 ms)
Minimum time between two
transients
50 s
Internal protection
Yes
1
The power loss generally corresponds to the specified value for power consumption.
Miscellaneous
Comfort HMI devices
KP1500 Comfort
TP1500 Comfort
TP1900 Comfort
TP2200 Comfort
Buffered real-time clock
1
Yes
Audio reproduction
Integrated or external via Line OUT
Magnetic field intensity
50/60 Hz; 100 A/m RMS
1
Battery backup typically 6 weeks
