Siemens SIMATIC HMI TP1200 Comfort User Manual

Mounting and connecting the HMI device
3.2 Mounting the device
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
45
Proceed as follows:
1. Insert the HMI device into the mounting cutout from the front. The figure shows a
KP700 Comfort as an example.
2. Insert the mounting clip into the cutout provided on the HMI device.
3. Tighten the grub screw to secure the mounting clip.
Note
Adhere to the permitted torque when tightening the grub screws of the mounting clips:
• 4" model: 0.2 Nm
• 7" to 22" models: 0.5 Nm
4. Repeat steps 2 and 3 for all mounting clips.
5. Check the fit of the mounting seal.
Result
The HMI device is mounted and the relevant degree of protection is ensured at the front.
See also
Accessories (Page 22)

Siemens SIMATIC HMI TP1200 Comfort Specifications

General

Display Size	12.1 inches
Resolution	1280 x 800 pixels
Power Supply	24 V DC
Display Type	TFT LCD
Brightness	400 cd/m²
Operating Temperature	0 to 50 °C
Relative Humidity	10% to 90% (non-condensing)
Interfaces	USB, RS422/RS485
Protection Class	IP65 (front)
Touch Technology	Projected capacitive touch (PCAP)
