Commissioning the device
4.2 Operating the device
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
71
Using the operating systems and Explorer
The table below shows the system key functions when using the operating system and the
Explorer:
Key or keyboard
shortcut
Function
Enables the taskbar and opens the Start menu.
Displays the loader.
Opens the task manager.
Toggles between the desktop and Explorer.
Navigates to the directory above.
Selects the first entry.
Selects the last entry.
Opens the shortcut menu.
Displays the properties.

Siemens SIMATIC HMI TP1200 Comfort Specifications

General

Display Size	12.1 inches
Resolution	1280 x 800 pixels
Power Supply	24 V DC
Display Type	TFT LCD
Brightness	400 cd/m²
Operating Temperature	0 to 50 °C
Relative Humidity	10% to 90% (non-condensing)
Interfaces	USB, RS422/RS485
Protection Class	IP65 (front)
Touch Technology	Projected capacitive touch (PCAP)
