1.1 IM151-1 HIGH FEATURE interface module (6ES7151-1BA02-0AB0)
IM151-1 HIGH FEATURE interface module (6ES7151-1BA02-0AB0)
10 Manual, 03/2008, A5E01075975-02
Technical data for the IM151-1 HIGH FEATURE interface module (6ES7151-1BA02-0AB0)
Dimensions and weight
Dimension B (mm) 45
Weight Approx. 150 g
Module-specific data
Data transmission rate 9.6; 19.2; 45.45; 93.75; 187.5; 500 kBaud, 1.5; 3;
6; 12 Mbit/s
Bus protocol PROFIBUS DP
Interface RS 485
SYNC capability yes
FREEZE capability yes
Manufacturer ID 80E0
H
Direct data exchange yes
Cycle synchronization Yes, from 1.5 Mbits/s
Parameter length 27 bytes
56 bytes, if cycle synchronization is active
Address space 244 bytes I/O
Option handling
• With reserve module
yes
• Without reserve module
yes
I&M data yes
Firmware update via PROFIBUS DP with HW Config
Max. output current of the PROFIBUS DP
interface (5, 6)
80 mA
Voltages, currents, potentials
Rated supply voltage of the electronics (1L+) 24 VDC
• Incorrect polarity protection
yes
• Power failure bypass
Min. 20 ms
Galvanic isolation
• Between the backplane bus and electronic
components
No
• Between the PROFIBUS DP and electronic
components
yes
• Between the supply voltage and electronic
components
No
Permitted potential difference (to the rail) 75 VDC / 60 VAC
Insulation test voltage 500 VDC
Current consumption from rated supply voltage
(1L+)
Approx. 200 mA
Power dissipation of the module Typically 3.3 W
