3.2 Option handling with RESERVE modules
IM151-1 HIGH FEATURE interface module (6ES7151-1BA02-0AB0)
Manual, 03/2008, A5E01075975-02
27
3.2.2 Prerequisites for option handling with RESERVE modules
Requirements
For option handling with RESERVE modules you require:
● An interface module that supports option handling with a RESERVE module.
● A power module that supports option handling with a RESERVE module.
● RESERVE modules as replacements for future electronic modules.
● GSD file SI0380E0.GSx for the IM151-1 HIGH FEATURE, as of 10/2006 (V1.0), for
configuration purposes.
Note
In
STEP 7
, you do not require a GSD file for option handling with the IM151-1 HIGH
FEATURE in the case of
STEP 7
V5.3 SP 3 or higher.
You can find the options handling description in the STEP 7 Online Help.
Note
If the actual configuration of an ET 200S station does not match the preset configuration, a
diagnostics report is generated if the check for the relevant slots is not enabled for option
handling.
