BIOS Setup (SCU)
3.7 Boot Menu
BIOS Description
38 Operating Manual, 05/2016, A5E33664825-AB
Normal Boot Menu Normal Boot order according to the type of bootable media.
This lists only the types of boot media for which at
least one bootable media is available.
Example: "CD/DVD-ROM Drive" can be selected as
the boot media type if a CD-ROM drive is installed as
a boot medium, for example.
Advance Custom boot order of all boot media. The boot media
and not the boot media types are individually listed.
Boot media that are disconnected from the device
and reconnected in between boot processes are
Exclusive
1
Can only boot from a SATA port which is defined at
the "Exclusive SATA Port for Legacy" parameter.
The following Setup parameter is visible if "Exclusive" is enabled:
• Exclusive SATA
Port for Legacy
Selection of the SATA port that is used during
booting.
Boot Type Order Submenu
2
for setting the boot sequence of the following boot media types.
Default setting:
1. Floppy drive
2. Hard Disk Drive
3. CD/DVD ROM Drive
4. USB
5. Others
for setting the boot sequence within the group of disk drives.
Hard Disk Drive Submenu
2
for setting the boot sequence within the group of hard disk
for setting the boot sequence within the group of optical drives.
for setting the boot sequence within the PCMCIA group.
for setting the boot sequence within the group of USB drives.
Others Submenu
2
for setting the boot sequence within the group of yet to be
detected boot media, for example, LAN/PXE ports (Remote Boot Devices).
PXE: LAN 1/2 Remote Boot: If PXE Boot capability is enabled (see above),
these are the PXE boot media for each LAN interface. When selected,
booting is via the network/PXE from this LAN port.
Only with IPC6x7 and IPC8x7 as of version V19.0x.05
Depends on the equipment: The submenu only appears if at least one boot device of this type is
