Overview
1.7 Design of the TP1500 Basic HMI device
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
Operating Instructions, 08/2008, A5E01075587-01
17
1.7 Design of the TP1500 Basic HMI device
① Display / touch screen ⑤ Power supply connector
② Recesses for mounting clamps ⑥ Rating plate
③ Mounting seal ⑦ Interface name
④ PROFINET interface ⑧ Connection for functional ground
