Overview
1.9 Accessories
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
Operating Instructions, 08/2008, A5E01075587-01
19
1.9 Accessories
The following accessories are available for the HMI devices in the Internet at
http://mall.automation.siemens.com
.
RS 422 to RS 232 converter
The converter is required to connect a SIMATIC S5 PLC and PLCs from other
manufacturers. Connect the RS 422 to RS 232 converter to the RS 422 / RS 485 interface.
The converter converts the input signals to RS-232 signals.
The converter is not included in the product package of the HMI device and is available
under the order number 6AV6 671-8XE00-0AX0.
PC/PPI cable
You need the PC/PPI cable to update the operating system with reset to factory settings.
You can also use the cable for data transfer. Connect the PC/PPI cable to the RS 422/485
port. The cable converts the input signals to RS-232 signals.
The cable is not included in the product package of the HMI device and is available under
order number 6ES7 901-3CB30-0XA0.
Note
Set a lower bit rate if the connection is lost during the operating system update. If you use a
higher bit rate, you must use the PC/PPI cable release 3 or higher. The version code is
printed on the cable (for example, "E-Stand 3" corresponds to version 3).
USB/PPI cable
You need the USB/PPI cable to update the operating system with reset to factory settings.
You can also use the cable for data transfer. Connect the PC/PPI cable to the RS 422/485
port. The cable converts the input signals to USB signals.
The cable is not included in the product package of the HMI device and is available under
order number 6ES7 901-3DB30-0XA0.
90° elbow adapter
You can use an elbow adapter at the RS 422/RS 485 interface to cope with confined spaces.
The adapter is not included in the product package of the HMI device. The adapter is
available under order number 6AV6 671-8XD00-0XA0.
