Technical specifications
8.8 Specifications
KTP400 Basic, KTP600 Basic, KTP1000 Basic, TP1500 Basic
96 Operating Instructions, 08/2008, A5E01075587-01
Supply voltage
KTP1000 Basic Color DP KTP1000 Basic Color PN TP1500 Basic Color PN
Rated voltage
Range, permissible
+24 VDC
19.2 to 28.8 V (–20%, +20%)
Transients, maximum permissible 35 V (500 ms)
Time between two transients,
minimum
50 s
Current consumption
• Typical
• Constant current, maximum
• Power on current surge I
2
t
Approx. 600 mA
Approx. 1000 mA
Approx. 0.2 A
2
s
Approx. 800 mA
Approx. 1000 mA
Approx. 0.2 A
2
s
Fuse, internal Electronic
Miscellaneous
KTP1000 Basic Color DP KTP1000 Basic Color PN TP1500 Basic Color PN
Realtime clock Yes, unbuffered
