Overview
1.2 Design
MP 377 15" Touch daylight readable (WinCC flexible)
Operating Instructions (Compact), 04/2009, A5E02532357-01
11
1.2 Design
Front view and side view
① Housing frame
② Front membrane
③ Display/touch screen
④ Protection for memory cards
⑤ Oblong holes for mounting clamps/air vents
⑥ Fans
⑦ Fixing element for strain relief
The term "front operating panel" as used in this manual corresponds to the front view with
operating elements.
Bottom view
① Mains terminal for power supply of HMI device
② Interfaces
③ Mains terminal for power supply of fans
④ Fans
