Technical specifications
8.4 Transport and Storage Conditions
MP 377 15" Touch daylight readable (WinCC flexible)
Operating Instructions (Compact), 04/2009, A5E02532357-01
57
8.4 Transport and Storage Conditions
Climatic transport and storage conditions
The transport and storage conditions of this HMI device exceed requirements conforming to
IEC 61131-2. The following specifications apply to the transport and storage of an HMI
device in its original packing.
The climatic conditions comply to the following standards:
● IEC 60721-3-3, Class 3K7 for storage
● IEC 60721-3-2, Class 2K4 for transport
Mechanical transport and storage conditions
The mechanical conditions correspond to IEC 60721-3-2, Class 2M2.
Type of condition Permitted range
Drop test (in transport package) ≤ 1 m
Temperature –40 to +80 °C
Atmospheric pressure 1 140 hPa to 660 hPa,
corresponds to an elevation of –1000 to 3500 m
Relative humidity 10 to 90 %, without condensation
Sinusoidal vibration conforming to
IEC 60068-2-6
5 to 8.4 Hz:
8.4 to 150 Hz:
3.5 mm
9.8 m/s
2
Shock conforming to IEC 60068-2-29 250 m/s
2
, 6 ms, 1,000 shocks
Temperature shock –40 to +80 °C, cycling time <= 3 min
