Technical specifications
8.2 Technical Specifications
MP 377 15" Touch daylight readable (WinCC flexible)
54 Operating Instructions (Compact), 04/2009, A5E02532357-01
8.2 Technical Specifications
Weight
Weight Approx. 4.6 kg
Degree of protection
Front IP66
Rear IP20
Display
Type LCD TFT
Material Glass
Glass thickness 3 mm
Hardness to Mohs 7
Colors, displayable 16 million
Backlighting
Half brightness lifetime, typical
LED
50 000 h
Display area, active 304.1 mm x 228.1 mm (15")
Resolution 1024 x 768 pixels
Dimming range 256 increments from 0 to 560 cd/m
2
The brightness values are recommended values.
Dimming range, limitable Yes
Contrast
• 700 : 1 typically
• 480 : 1, minimum
Response time < 20 ms
Input unit
Type Touchscreen, projected capacitive
Operability
• Finger
• Finger with thin glove
Calibration points 9
Memory
Application memory 12 MB
