Planning application
3.3 Preparation for mounting
MP 377 15" Touch daylight readable (WinCC flexible)
Operating Instructions (Compact), 04/2009, A5E02532357-01
27
Maintaining clearances
The HMI device must be installed with the following clearances:
Where Clearance
Observe a clearance above and below the mounting cutout for
ventilation of
50 mm
Right and left of the mounting cut-out for the mounting clamps 18 mm
At the rear in addition to the mounting depth of the HMI device at
least
≥ 10 mm
Note
Ensure that the maximum ambient temperature is not exceeded when mounting the device
in a control cabinet.
You can install the option "TEK – Temperature Extension Kit", if necessary.
