Siemens SIMATIC NET CP 343-1 User Manual

english
1
Product information CP 343–1
C79000–Z8964–C038–05
Contents
Notes for the Reader 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 The CP 343-1 Communications Processor 3. . . . . . . . . . . . . . .
1.1 Characteristics 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Performance Data 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.1 Characteristics of S7 Communication 7. . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2.2 Characteristics of ISO Transport Connections 7. . . . . . . . . . . . . . . . . . .
1.3 Displays and Mode Selector 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Further Information on Operation 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Installation 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Module Accessories 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Procedure 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Attaching the CP 343-1 to Industrial Ethernet 13. . . . . . . . . . . . . . . . . . . .
3 Technical Data 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 General Technical Data 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Pinout 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Notes on the CE Approval of SIMATIC NET Products 17. . . . . . . . . . . . .
4 References 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compatibility with the Previous Version
The version of the CP 343-1 described here is functionally compatible with and can
be used to replace the CP 343-1 with order number 6GK7 343–1BA00–0XE0 ver-
sion 6.
The CP 343-1 decribed here has more functions. Refer to the information in
Section 1.1.
Reply Form (at the end of this product information):
We would like to know the purpose for which you are using this module
and would also like to know your opinion of the module and the documen-
tation. You can help us to provide you with better support and to further
improve the product. We would be grateful if you would complete the reply
form and return it to us by post or fax.
